Slopetame3
Erosion Control System
Made From 100% Recycled Plastic
Slopetame3 provides an immediate and permanent solution to erosion and sedimentation problems. Using the trademark interlocking ring-on-grid design with the added benefit of crossbars on every row Slopetame3 is a reinforcement and stabilization system. The attached geotextile filter fabric will never come off and allows for the growth and containment of vegetation. Even with only a 1” depth required Slopetame3 can permanently stabilize slopes with angles up to 45 degrees.
Learn More About Slopetame3
The 100% recycled plastic rolls are lightweight and easy to install. Secured with a provided duckbill anchor and single rebar, one person can install 430 sf of product in approximately 10 minutes. Slopetame3 can be bent and trimmed with pruning shears to achieve curves, avoid trees and create custom layouts.
Made in the USA
Tame These Applications
- Steep Slope Erosion Control
- Bank Stabilization
- Vegetated Swale Applications
- Stormwater Infiltration Trenches
- 1:1 Slope Erosion Control
The Slopetame3 Benefits
- Permanent Stabilization
- Vegetation Containment
- Controlled Porosity
- Lightweight and Easy to Install
- UV Resistant
- 100% Recycled Plastic
Slopetame3 Sales SheetLanguage: English |
Product Family BrochureLanguage: English |
Technical Specification – Slopetame2 Slope and Channel ProtectionLanguage: English |
Slopetame2 Material Safety Data SheetLanguage: English |
H-20 and HS-20 loadingLanguage: English |
Leed v3 and ISILanguage: English |
LEEDv3 and ISI by ProductLanguage: English |
Preserving Fresh Water Resources with Invisible StructuresLanguage: English |
Dramatic Curve Cutting TechniquesLanguage: English |
Dramatic Curve Cutting Techniques
Language: English
View Online Download
Preserving Fresh Water Resources with Invisible Structures
Language: English
View Online Download
LEEDv3 and ISI by Product
Language: English
View Online Download
Leed v3 and ISI
Language: English
View Online Download
H-20 and HS-20 loading
Language: English
View Online Download
Slopetame2 Material Safety Data Sheet
Language: English
View Online Download
Technical Specification – Slopetame2 Slope and Channel Protection
Language: English
View Online Download
Product Family Brochure
Language: English
View Online Download
Slopetame3 Sales Sheet
Language: English
View Online Download
What is Slopetame3?
Slopetame3 is a permanent erosion control mat comprised of ISI’s trademark ring-on-grid system, crossbars on every row and a permeable vegetative fabric layer. Duckbill anchors are provided to secure every roll.
What is the difference between Slopetame2 and Slopetame3?
The new design has larger rings, making the whole roll lighter and easier to install. We also added cross-bars to every row (formerly every other) to further assist in the instant containment of erosion.
What is the difference between Slopetame3 and other erosion control solutions?
Slopetame3 is unique in that it is an immediate and permanent solution. The three-dimensional containment system is installed just an inch below ground and isn’t visible from the surface. The permanent fabric backing allows for both containment and root growth/penetration for vegetation.
How does the cost of Slopetame3 compare to other erosion control solutions?
Slopetame3 is initially more expensive than other erosion control mats but is a permanent solution that will not require maintenance or need to be replaced. Slopetame3 is generally less expensive than the installation of a gabion or retaining wall.
What is the required depth for Slopetame3?
Only a 1” depth is required for vegetation and/or gravel fill.
What is the maximum slope angle Slopetame3 can support?
Slopetame3 can permanently stabilize slopes up to 45 degrees or a 1:1 ratio.
Can Slopetame3 be used on a grass slope intended for pedestrian or vehicular use?
Slopetame3 can be used and will support the weight of pedestrian and most vehicular. However, grass on a slope can be extremely slippery and these installations should be done with care.
Typical Slopetame2 Details |
Swale and Channel Reinforcement with Slopetame2 |
Slopetame2 at Ponds Edge |
Retention Pond Soil Reinforcement with Slopetame2 |
Detention Pond Reinforcement with Slopetame2 |
Typical Slopetame2 Details
Swale and Channel Reinforcement with Slopetame2
Slopetame2 at Ponds Edge
Retention Pond Soil Reinforcement with Slopetame2
Detention Pond Reinforcement with Slopetame2
Manufactured in 1 square meter units (3.3′ x 3.3′) and assembled into rolls 1m x 10m or 2m x 20m. Rolls can be cut as needed on site with pruning shears. Some curves can be achieved without cutting. Please review the roll chart for more details.
|
Width |
Length |
Diameter |
Area |
Approx. Weight |
||||||
|
Model |
m |
ft |
m |
ft |
m |
ft |
m2 |
ft2 |
kg |
lbs |
|
1010 |
1 |
3.3 |
10 |
32.8 |
0.5 |
1.7 |
10 |
108 |
22 |
48 |
|
2020 |
2 |
6.6 |
20 |
65.6 |
0.8 |
2.7 |
40 |
430 |
87 |
192 |
- Size: 2 roll sizes
- Color: black – standard, color – custom order
- Weight: 2.0 kg/m2 (.42 lbs/sf)
- Strength: 1120.69 kg/cm2 (15,940 psi) when filled with sand.
